    M5 Gantry Overhead Crane 15T Electric Wire Rope Hoist

    Ask Lasest Price
    Brand Name : JCYC
    Model Number : SHSL
    Certification : CE&ISO
    Price : Negotiable
    Payment Terms : L/C, T/T, Western Union, D/A, D/P, MoneyGram
    Supply Ability : 1000 units per month
    Delivery Time : 10 -15 working days
    • Product Details
    • Company Profile

    M5 Gantry Overhead Crane 15T Electric Wire Rope Hoist

    Overhead Single Girder Crane 15T Electric Wire Rope Hoist European Model


    Product Introduction


    European Type Electric Wire Rope Hoist

    It is latest designed internation standard product by combining and applying the advanced German technologies. It has compact structure and its frame is in rectangular shape. Its drum is made of seamless steel pipe. Its planetary gearbox, which is in the hoisting drum, electromotor and electric control box is in beeline collocation. The hoist has overload protection, overheating protection and phase relay protection devices. Its modular design can realize the seamless connection with frequency inverter, automatic weighing system and automatic detection system.


    Application


    It is widely used for overhead crane, gantry crane etc. heavy duty industry, light duty industry especially highly resticted environment plants. Especially for the places with high environmental requirements.


    Features


    * Trolley with frequency conversion motor
    * Double speed/frequency conversion lifting motor
    * Motor protection grade IP55, Insulation grade F
    *Electromagnetic disc brake, maintenance-free
    * Control volatege 24v/26v/48v/110v
    * Schneider contactor & Inverter
    * 380V/415V/440V/460V/3PH/50/60HZ
    *Lifting limit switch
    *Hook, with safety latch
    * Overload limiter
    *Ambient temperature: -20ºC~+40ºC
    *Motor over temperature protection


    Technical Parameters


    Capacity tonLifting height mLifting speed m/minLifting motor kwTraveling speed m/minTraveling motor kwLifting System FEM/ISOTraveling System
    FEM/ISO
    I-Beam Width mm
    2t6/9/12/15/185/0.83.2/0.455/200.373MM62MM5150-300
    3.2t6/9/12/15/185/0.83.2/0.455/200.372MM52MM5150-300
    5t6/9/12/15/185/0.86.1/15/200.372MM52MM5200-350
    6.3t6/9/12/15/185/0.86.1/15/200.371AmM42MM5200-350
    8t6/9/12/15/185/0.89.5/1.55/200.753MM62MM5200-410
    10t6/9/12/15/185/0.89.5/1.55/200.752MM52MM5200-410
    12.5t6/9/12/15/184/0.612.5/25/200.751AmM42MM5200-410
    16t6/9/12/15/184/0.616/2.65/200.75x22MM52MM5300-450
    20t6/9/12/15/184/0.616/2.65/200.75x21AmM42MM5300-450
    8t20/24/28/32/368/1.312.5/25/200.752MM52MM5200-410
    10t20/24/28/32/368/1.316/2.65/200.752MM52MM5200-410
    12.5t20/24/28/32/366.3/116/2.65/200.751AmM42MM5200-410



    Product show



    Quality M5 Gantry Overhead Crane 15T Electric Wire Rope Hoist for sale
